Linux Document Scanner



Here’s how you can scan documents from a live camera stream with Python. This example uses OpenCV for camera capture and display and the Scanbot Linux SDK for real-time document detection. The command-line interface accepts a single image path as input, and the Scanbot SDK license key is embedded directly in the source code. The implementation is split into several small, reusable components:

Head over to the Linux Document Scanner SDK documentation for a quick start guide on how to scan documents from still images.

Requirements

Make sure you have these packages installed:

pip install scanbotsdk opencv-python numpy

Your system must also provide:

• • GStreamer plugins if using jetson_csi or libcamera pipelines

• • A camera device (USB webcam, Jetson CSI, or libcamera-compatible camera)

Optional: Install CUDA + TensorRT

Requires Jetpack 6.1, CUDA 12.6, and TensorRT 10.3 for GPU acceleration.

sudo apt install -y nvidia-l4t-cuda libnvinfer10 libnvinfer-plugin10 libnvonnxparsers10

Camera helper

import cv2 as cv

# Default camera settings (resolution and framerate)
WIDTH, HEIGHT, FPS = 1280, 720, 30

def _gst_pipeline(device: str) -> str:
    if device == "jetson_csi":
        return (
            "nvarguscamerasrc ! "
            f"video/x-raw(memory:NVMM), width=(int){WIDTH}, height=(int){HEIGHT}, "
            f"framerate=(fraction){FPS}/1 ! "
            "nvvidconv flip-method=0 ! "
            "video/x-raw, format=(string)BGRx ! "
            "videoconvert ! video/x-raw, format=(string)BGR ! appsink drop=1"
        )
    if device == "libcamera":
        return (
            "libcamerasrc ! video/x-raw, format=BGR, "
            f"width=(int){WIDTH}, height=(int){HEIGHT}, "
            f"framerate=(fraction){FPS}/1 ! appsink"
        )
    raise ValueError(f"Invalid device for GStreamer: {device!r}")


def open_camera(device: str) -> cv.VideoCapture:
    """Open V4L2 (numeric index) or GStreamer ('jetson_csi' / 'libcamera')."""
    try:
        cap = cv.VideoCapture(int(device), cv.CAP_V4L2)
        cap.set(cv.CAP_PROP_FRAME_WIDTH, WIDTH)
        cap.set(cv.CAP_PROP_FRAME_HEIGHT, HEIGHT)
        cap.set(cv.CAP_PROP_FPS, FPS)
    except ValueError:
        cap = cv.VideoCapture(_gst_pipeline(device), cv.CAP_GSTREAMER)
    if not cap.isOpened():
        raise RuntimeError("Cannot open camera")
    return cap

• • Opens a camera using V4L2 (numeric index like "0") or GStreamer ("jetson_csi" / "libcamera").

• • Requests 1280×720 @ 30fps.

Device strings:

• • "0", "1" — USB webcams via V4L2

• • "jetson_csi" — Jetson CSI camera (nvarguscamerasrc)

• • "libcamera" — modern libcamera-based pipeline (e.g., Raspberry Pi OS Bookworm)

Document scanner

Creates a DocumentScanner instance with ProcessingMode.AUTO.

def create_document_scanner() -> DocumentScanner:
    config = DocumentScannerConfiguration(
        processing_mode=ProcessingMode.AUTO,
    )
    return DocumentScanner(configuration=config)

def print_documents_text(res: DocumentDetectionResult, frame):
    print(res.status.name)
    return None

Scanning loop

import cv2 as cv
from scanbotsdk import ImageRef, RawImageLoadOptions

from snippets.live.preview import preview_on_frame

def run_scanner(cap: cv.VideoCapture, scan, on_result):
    """Read frames, run scanner, and show processed frame if returned."""
    show_preview = None
    try:
        while True:
            ok, frame = cap.read()
            if not ok:
                break

            with ImageRef.from_ndarray(frame, RawImageLoadOptions(live_source=True)) as img:
                res = scan(image=img)

            frame_to_show = on_result(res, frame)
            if frame_to_show is not None:
                if show_preview is None:
                    show_preview = preview_on_frame("Live")
                show_preview(frame_to_show)
    except KeyboardInterrupt:
        pass
    finally:
        cap.release()

• • Each captured frame is wrapped in an ImageRef with live_source=True for maximum FPS.

• • Continuously reads frames from the camera.

• • Sends them to the scanner.

• • Passes results to an on_result callback.

Optional: Live preview window

import cv2 as cv

def preview_on_frame(window_name: str = "Live"):
    cv.namedWindow(window_name, cv.WINDOW_AUTOSIZE)

    def _on_frame(frame):
        cv.imshow(window_name, frame)
        if cv.waitKey(1) == 27:  # ESC
            cv.destroyAllWindows()
            raise KeyboardInterrupt

    return _on_frame

This displays the processed frame in a real-time window. Press ESC or close the window to stop.

def draw_documents_frame(res: DocumentDetectionResult, frame, color=(0, 255, 0), thickness=2):
    pts_list = list(res.points or [])
    if not pts_list and res.points_normalized:
        h, w = frame.shape[:2]
        pts = np.array([[int(p.x * w), int(p.y * h)] for p in res.points_normalized], dtype=np.int32)
    elif pts_list:
        pts = np.array([[int(p.x), int(p.y)] for p in pts_list], dtype=np.int32)
    else:
        return frame

    # Draw contour
    cv.polylines(frame, [pts], True, color, thickness, cv.LINE_AA)

    # Put status label above the top-most vertex
    top_idx = int(np.argmin(pts[:, 1]))
    x, y = int(pts[top_idx, 0]), int(pts[top_idx, 1])
    y = max(0, y - 6)
    label = res.status.name
    cv.putText(frame, label, (x, y), cv.FONT_HERSHEY_SIMPLEX, 0.5, color, 1, cv.LINE_AA)

    return frame

Running the example

The document_live function combines all components into a runnable demo. It opens the camera, creates the document scanner, and starts the scanning loop with or without a live preview window.

def document_live(device_input: str, show_preview: bool):
    cap = open_camera(device_input)
    scanner = create_document_scanner()
    if show_preview:
        run_scanner(cap, scanner.run, on_result=draw_documents_frame)
    else:
        run_scanner(cap, scanner.run, on_result=print_documents_text)

Performance tip (for NVIDIA Jetson)

To avoid throttling, set max GPU/CPU/memory clocks:

sudo jetson_clocks --store
sudo jetson_clocks

To later restore the defaults, run:

sudo jetson_clocks --restore
